    50FT Octagonal Electrical Power Pole for Power Transmission 10 KV 550 KV 1.8 Safety Factor

    Ask Lasest Price
    Brand Name : milky way
    Model Number : yin-he
    Certification : ISO BV
    Price : USD 130-180/piece
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1000pieces per month
    Delivery Time : always 2 weeks
    • Product Details
    • Company Profile

    50FT Octagonal Electrical Power Pole for Power Transmission 10 KV 550 KV 1.8 Safety Factor

    Specifications:


    Suit forPower Transmission
    ShapeConoid ,Multi-pyramidal,Columniform,polygonal or conical
    Power10 KV ~550 KV
    Safety FactorSafety factor for conducting wine : 8
    Safety factor for grounding wine : 8
    Wind Speed33 m /s
    Minimum yield strength355 mpa
    Minimum ultimate tensile strength490 mpa
    Max ultimate tensile strength620 mpa
    StandardISO 9001
    Length of per sectionWithin 14m once forming without slip joint
    WeldingWe has past flaw testing.Internal and external double welding makes
    the welding beautiful in shape
    Welding Standard :AWS ( American Welding Society ) D 1.1
    Production ProcessRow material test → Cutting →Molding or bending →
    Welding (longitudinal )→Dimension verify →Flange welding
    →Hole drilling →Calibration → Deburr→Galvanization or
    powder coating ,painting →Recalibration →Thread →Packages
    PackagesOur poles as normal cover by Mat or straw bale at the top and bottom ,
    anyway also can following by client required , each 40HC or OT can
    loading how many pcs will calculation base on the client actually
    specification and data

    The followed design is based on ASTMA 572 Gr 65 material,with octagonal cross section shape,while the safety factor is 1.8.If you have other requirement on load,height,material and cross section shape,pls contact us.


    Description:

    Standard Accessory

    -Top plate

    -Base plate

    -Bottom strip

    -Standard hole

    -Climbing rung

    -Anchor bolt

    -Bitumen protection

    -Painted marking

    -Removable ladder

    15m 1000DAN Electrical Utility Poles GR505 Material For Congo Electric Distribution 0


    The information to inquiry or purchase
    -Steel pole height and force
    -Cross arm type and length,the position to install in the steel pole
    -The method to fix the cross arm(use bolt to connect or use one or two template to weld in the steel pole to install the cross arm)
    -Safety factor of the steel pole
    -Wind speed
    -Type of climbing rung
    -Destination port
    -Other.


    Pole Dimension

    15m 1000DAN Electrical Utility Poles GR505 Material For Congo Electric Distribution 1


    Company Introduction:
    Jiangsu Milky Way Steel Poles which established on 1991 is located in Wuxi,East of China ,near one of the largest sea port of China ,Shanghai,Port .
    Our Company has 24 years experience on producing the steel poles including the transmission power pole,street light pole,high mast pole and so on.
    We exported to oversea countries since 1991 and our products have been delivered to more than 70 countries and areas ,including America,Australia ,Russia ,Germany ,Span,Philippines ,Malaysia,Africa and so on.
    We are the supplier of many big project in many countries,like the street light pole of Dubai Tower.the high mast pole for Sochi Winter Olympic Game and so on.
