    30FT 35FT 500kg load Philippines Transmission Pole Electric Pole NEA NGCP Standard

    Ask Lasest Price
    Brand Name : Milky Way
    Model Number : 30FT 35FT 500kg load Philippines Transmission Pole Electric Pole NEA NGCP Standard
    Certification : /BV/ISO
    Price : negotiation
    Payment Terms : T/T
    Supply Ability : 300 pieces pole per day
    Delivery Time : usually 2 weeks after confirming
    • Product Details
    • Company Profile

    30FT 35FT 500kg load Philippines Transmission Pole Electric Pole NEA NGCP Standard

    Hot Dip Galvanized Power Transmission Poles For Electrical Line Project


    Specification:



    Material:

    high quality Q345 hot rolled steel

    Mounting Height:

    3-30m or according to the requirements of customers

    Shape of pole:

    Round,conical,octagonal,square,mid hinged,polygonal shafts are made of steel sheet that folded into required shape and welded longitudinally by automaticarc welding machine

    Brackets:

    Single or double brackets are in the shape and dimension as per customers requirement

    Base plate:

    Base plate is square or round in shape with slotted holes for anchor bolt and dimension as per customers requirement


    Groung mounted:

    The length buried underground as per customers requirement


    Galvanizing:

    Hot dip galvanization with thickness of 80-100µm average


    Powder coating:

    Pure polyester powder painting, color is optional


    Process

    Raw material

    When purchasing the raw material (steel plate), on sheet of mill certificate from mill factory must be enclosed. When the raw material arrives at the warehouse, the quality department must take the elongation test and the chemical composition analysis to make sure the raw material have meet all the standard that the needed before production.

    Plasma Cutting

    Cutting the raw material that have meet all the standard required into different length and width. CNC laser cutting is used to direct the material or the laser beam generated. A typical commercial laser for cutting materials would involve a motion control system to follow a CNC or G-code of the pattern to be cut onto the material. The focused laser beam is directed at the material, which then either melts, burns, vaporizes away, or is blown away by a jet of gas, leaving an edge with a high-quality surface finish.

    Molding

    Forming the cut steel plate into the shape (circular or polygonal or other shape ) that as per specified in the drawing. This invention relates to forming devices and more particularly to devices or machines for bending longitudinally rolled sections or strips of metal stock to desired curvilinear shapes.

    Welding

    After molding, weld the steel plate together. Usually it is longitudinal welds. It adopts A.C.inverter control, with functions of stable running and fast traveling speed; The seam-tracking arc-guide mechanism is three-spindle system to guarantee the alignment without aberrancy; The main frame and welding machine are intergrated control, with flux auto-recovering system and it is easy to operate with high efficiency.

    Galvanization

    All poles internally and externally are to be hot-dip galvanized in accordance with requirement mentioned in the relevant drawing or specification
    Galvanization standard:IS2629-1985 ,BS729-1971



    About Milky Way
    Established in 1991,Jiangsu Milky Way Steel Poles is located in Wuxi,East of China ,near one of the largest sea port of China ,Shanghai,Port . Our Products have been widely used in the power transmsion ,signal transmission and ligting for street ,road ,square ,palaestra.and so on.
    We have plenty of export experience . Since our first overseas order from Pakstan in 1991 of 132 KV transmission poels ,our products have been deliveried to more than 70 contries and areas ,including America,Australia ,Russia ,Genmery ,Span,Philippines ,Malaysia , Dominica, Congo, Togo and Guniea so on.
