High Precision Pure Copper Weld Steel Ground Rod Well Agglutination

Ask Lasest Price
Brand Name :	Milky Way
Model Number :	ground rod
Certification :	CE,UL467,ISO9001:2008
Price :	US $0.1-5 per piece
Payment Terms :	L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability :	500 tons per month
Delivery Time :	5-15 days

Add to Cart

Product Details
Company Profile

High Precision Pure Copper Weld Steel Ground Rod Well Agglutination

High Precision pure copper weld steel ground rod with accessories

Specifications:

Ground Rod Size List
Small Size
Model	Diameter		Copper Thickness		Length		N.W.	Packing
Model	inch	mm	Mil	mm	Feet	mm	kgs/pc	pc/bundles
YH-8		8	10	0.254	3	900	0.45	20
YH-8		8	10	0.254	4	1200	0.45	20
YH-8		8	10	0.254	5	1500	0.45	20
YH-9		9	10	0.254	3	900	0.57	20
YH-9		9	10	0.254	4	1200	0.57	20
YH-9		9	10	0.254	5	1500	0.57	20
YH-10		10	10	0.254	3	900	0.7	20
YH-10		10	10	0.254	4	1200	0.7	20
YH-10		10	10	0.254	5	1500	0.7	20
YH-11		11	10	0.254	3	900	0.85	20
YH-11		11	10	0.254	4	1200	0.85	20
YH-11		11	10	0.254	5	1500	0.85	20
YH-12		12	10	0.254	3	900	1.01	20
YH-12		12	10	0.254	4	1200	1.01	20
YH-12		12	10	0.254	5	1500	1.01	20
YH-13		13	10	0.254	3	900	1.18	20
YH-13		13	10	0.254	4	1200	1.18	20
YH-13		13	10	0.254	5	1500	1.18	20
YH-13		13	10	0.254	6	1800	1.18	20
YH-14	5/8	14..2	10	0.254	4	1200	1.54	20
YH-14	5/8	14.2	10	0.254	6	1800	2.3	10
YH-14	5/8	14.2	10	0.254	8	2400	3.07	10
YH-14	5/8	14.2	10	0.254	10	3000	3.84	10
YH-14	5/8	14.2	10	0.254	20	6000	7.68	5
YH-16		14.2	10	0.254	4	1200	1.95	10
YH-16		16	10	0.254	6	1800	2.93	10
YH-16		16	10	0.254	8	2400	3.9	10
YH-16		16	10	0.254	10	3000	4.88	10
YH-16		16	10	0.254	20	6000	9.75	5
YH-17	3/4	17.2	10	0.254	4	1200	2.25	10
YH-17	3/4	17.2	10	0.254	6	1800	3.38	10
YH-17	3/4	17.2	10	0.254	8	2400	4.51	10
YH-17	3/4	17.2	10	0.254	10	3000	5.64	7
YH-17	3/4	17.2	10	0.254	20	6000	11.27	5
YH-18		18	10	0.254	4	1200	2.47	10
YH-18		18	10	0.254	10	3000	6.17	7
YH-18		18	10	0.254	20	6000	12.34	5
YH-20		20	10	0.254	6	1800	4.57	10
YH-20		20	10	0.254	8	2400	6.1	10
YH-20		20	10	0.254	10	3000	7.62	7
YH-20		20	10	0.254	20	6000	15.24	5
YH-20		20	10	0.254	8	2400	6.1	10
YH-22		22	10	0.254	10	3000	9.22	7
YH-22		22	10	0.254	6	1800	5.53	10
YH-25		25	10	0.254	8	2400	9.53	10
YH-25		25	10	0.254	10	3000	11.91	7
YH-25		25	10	0.254	20	6000	23.81	5
Also supply copper layer thickness 0.33mm,0.5mm and 1.0mm
Also supply any length shorter than 6000mm

Description:
The counter bored couplings are made from high copper content alloy, earth rod,commercial brass is not used.

This again ensures excellent corrosion resistance and high strength.

Item Number	copper weld steel ground rod
Copper layer thickness	>=0.254mm
Tensile strength	>=600Nm/mm2
Straightness error	<=1mm/m
Service life	>=50years
Function	Used in grounding and lightning system
Type	Threaded or flat or pointed
Plasticity of copper layer	No crack under U bent
Available service mode	OEM;ODM
Certificate	CE,UL467,ISO9001:2008

Packaging & Shipping:
5pcs/bundle 10pcs/bundle Nylon strip-Weave strip-Iron pallet or wooden case-Container 3 tons per pallets 20 tones per container.

Company introduction:
Estbilsed in 1991,Jiangsu Milky Way Steel Poles is located in Wuxi,East of China ,near one of the largest sea port of China ,Shanghai,Port .Our Products have been widely used in the power transmsion ,signal transmission and ligting for street ,road ,square ,palaestra.and so on.
