33KV 18m Galvanized octagonal Power Transmission Poles design steel
tower
Specifications
1. Protecion class: IP65
2. Light source: 100W-400W high-pressure sodium lamp
3. Rated voltage and frequency: 220V(±10%)/50Hz
4. Caliber: 60mm
5. Protecting class against eletric shock: Type I
6. Lamp in die-cast aluminum, coated with powder polyes ter after
anti-corrosive treatment
7. A lamp body with a built-ray lens
8. Fasteners screws, all stainless steel
9. Applicable height: 6m-12m (according to customers' requirment)
10. Working environment:-35°C--+55°C
11. Long term life :more than 100,000 hours
12. Nast of steel, coated with powder polyester after hot
galvanizing treatment
13. Lamp can adjust up,down or around and can be changed the
projection angle
14. Environmentally friendly:instead of liquid mercury, easy to
recycle
15. Applicable places: City Road,overpass,factory
areas,bridge,harbour and etc.
| Item | TIP DIAMETER | BUTT DIAMETER | THICKNESS | Pole Shape |
| (m) | (MM) | (MM) | (MM) | 8 sides |
| 11.8m/5KN | 150 | 355 | 3 |
| 11.8m/6.5KN | 180 | 400 | 3 |
| 11.8m/8KN | 190 | 440 | 3 |
| 11.8m/10KN | 190 | 450 | 3.5 |
| 11.8m/12.5KN | 220 | 500 | 3.5 |
| 11.8m/16KN | 230 | 560 | 3.5 |
| 11.8m/20KN | 240 | 585 | 4 |
| 11.8m/25KN | 260 | 655 | 4 |
| 11.8m/32KN | 260 | 660 | 5 |
| 11.8m/40KN | 260 | 670 | 6 |
| 16m/5KN | 150 | 375 | 4 |
| 16m/6.5KN | 180 | 420 | 4 |
| 16m/8KN | 190 | 460 | 4 |
| 16m/10KN | 190 | 510 | 4 |
| 16m/12.5KN | 220 | 525 | 4 | 12 sides |
| 16m/16KN | 230 | 585 | 4 |
| 16m20KN | 240 | 585 | 5 |
| 16m/25KN | 260 | 655 | 5 |
| 16m/32KN | 260 | 670 | 6 |
Packaging detail
Packed with good cartons and bubble wrap(the pole can be packed by
bubble wrap,the lamp head can be packed by carton.Specific details
according to customer's demands)
Delivery detail
15-20 days received the deposit(Specific details according to
actual situation)
It can be used on main highway,main street,commercial center,etc.
outdoor place.
We can according to your design and drawings to produce. If you
only need light pole,we are also provide for you.
The above configuration is for reference only. If you are
interested in,please feel free to contact us for more information
at anytime.
Our Promises
1. Offer customer the lowest price with high quality
2. Streamline the buying and paying processes.
3. Delivery the goods to our customer all over the world with speed
and precision.
4. Ensure the excellent quality of our products
Payment Method
We accept T/T, western union payment now. For more payment
information please feel free to contact us.
Company Information
Estabilsed in 1991,Jiangsu Milky Way Steel Poles is located in
Wuxi,East of China ,near one of the largest sea port of China
,Shanghai,Port .
Our Products have been widely used in the power transmsion ,signal
transmission and ligting for street ,road ,square ,palaestra.and so
on
We have plenty of export experience . Since our first overseas
order from Pakstan in 1991 of 132 KV transmission poels ,our
products have been deliveried to more than 70 contries and areas
,including America,Australia ,Russia ,Genmery ,Span,Philippines
,Malaysia and so on
