    33kv Philippines Steel Power Pole 90ft With Angle Arms For Power Distribution

    Ask Lasest Price
    Brand Name : milky way
    Model Number : Steel Power Pole
    Certification : ISO9001:2015
    Price : 130-180USD/pieces
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1000 per month
    Delivery Time : 2 weeks always
    • Product Details
    • Company Profile

    33kv Philippines Steel Power Pole 90ft With Angle Arms For Power Distribution


    33kv Philippines Steel Power Pole With Angle Arms For Power Distribution

    Product Description


    Type
    Straight Pole ,Tensile Pole ,Turn Pole
    Material:
    Usually Q345B/A572,minimum yield strength>=345n/mm2
    Q235B/A36,minimum yield strength>=235n/mm2
    As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, to ST52-
    Shape
    Conoid ,Multi-pyramidal,Columniform,polygonal or conical
    Safety Factor
    Safety factor for conducting wine : 8
    Safety factor for grounding wine : 8
    Design Load in Kg
    300~ 1000 Kg appliced to 50cm from the to pole
    Marks
    Nane plate through rivert or glue ,engrave ,emboss as per customer requirement
    Surface treatment
    Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.
    Joint of Poles
    Insert mode,inner flange mode,face to face joint mode .
    Design of pole
    Against earthquake of 8 grade
    Length of per section
    Within 14m once forming without slip joint
    Welding
    We has past flaw testing.Internal and external double welding makes the welding beautiful in shape
    Welding Standard :AWS ( American Welding Society ) D 1.1
    Production Process
    Raw material test → Cutting→Molding or bending →Welding (longitudinal )→Dimension verify→Flange welding →Hole drilling →Calibration → Deburr→Galvanization or powder coating ,painting →Recalibration →Thread →Packages
    Minimum yield strength
    355mpa
    Minimum ultimate tensile strength
    490mpa
    Max ultimate tensile strength
    620mpa



    Asides above, we can also supply the poles based on customer's request. And different specification poles with different price. On the other side, the price is according to each pole weight. The heavier the more expensive. So to save the cost, our factory has the professional technical team to design the practical poles and save the cost for our clients.





    FAQ
    Q1. How can I get a price of needed pole?
    A: 1. Please give the exactly dimensions such as height, thickness, material, top and bottom dia. We can according to your specification give you a similar price.
    2. You can send us a drawing; we can according to your drawing give you one price.


    Q2. I am a small wholesaler, do you accept small order?
    A: It's no problem if you are a small wholesaler; we would like to grow up with you together.


    Q3. I am a designer; Can you help me to produce the sample which we designed?
    A: Our mission is to help customers to be successful. So it's welcome if we can help you solve problem and make your design come true.
    Q4. We want be your agent of our area. How to apply for this?
    A: Please send your idea and your profile to delia @yin-he.com
    Q5. Tell me about your company?
    A:Jiangsu Milky Way Steel Poles Co.,Ltd , we have been a manufacturer and exporter of all kinds of steel poles, including street lighting pole,power transmission pole, floodlighting pole for large squares and other steel products since 1991.Our poles have been exported to more than 70 countries and areas.
    Q6. Do you have some special policies for Brand company?
    A:Yes, we have some special support for the company who has own brand but also in our VIP customers list. Please send us your selling data of last year. So we can see how to support you for your products in your market.
    Q7. Can you make Door to Door service? Because i don't know how to do customs clearance.
    A:Yes. We can make Door to Door service to help you save much time of shipping. Also we have big discount with shipping company because we have do much of this every day. So it will save your time also money.
