    Gr65 Steel Tubular Pole High Mast Light Pole Single Double / Triple Arm For Stadium

    Ask Lasest Price
    Brand Name : MilkyWay
    Model Number : High Mast Pole
    Certification : ISO9001/BV/
    Price : Negotiation
    Payment Terms : T/T, L/C at sight
    Supply Ability : 300pcs per day
    Delivery Time : 20 working days after received your payment
    • Product Details
    • Company Profile

    Gr65 Steel Tubular Pole High Mast Light Pole Single Double / Triple Arm For Stadium

    Gr65​ steel poles steel tubular pole High Mast Pole for stadium


    High mast pole Gr65 steel materialsmooth welding noedgeHDG ,powder coated


    1)Steel materials:Gr65 or ss400

    2)8-15 meters pole,vary from person to person
    3)Lithium arc welding,tighten
    4)Hot-dip galvaniation and powder coating,anti-corrosion,aging

    resistant
    5)Pole shape:square and round conical,tubular stepped
    6)Base plate mounted:base plate is square or round in shape with slotted holes for anchor bolt
    7)Single,double or triple arm
    8)Fair price and easy maintance
    9Strict control and test measures ensure the high quality

    These above instructions are for reference only.
    Color, size, specifications and packaging mainly depend on customers' demand


    street lighting high mast polesstreet lighting high mast polesstreet lighting high mast polesstreet lighting high mast polesstreet lighting high mast polesstreet lighting high mast poles


    Specification:

    20-50 meters high mast pole

    Type

    high mast pole

    Shape

    conical, hexagonal and octagonal

    Material

    Usually Q345B/A572,minimum yield strength>=345n/mm2
    Q235B/A36,minimum yield strength>=235n/mm2
    As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490ST52

    Torlance of dimenstion

    -0.02

    Design Load in Kg

    300~ 1000 Kg appliced to 50cm from the to pole

    Surface treatment

    Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.

    Standard

    Octagonal Conical tapered column
    Certified by SIRIM QAS INTERNATIONAL.
    Approved by JABATAN KERJA RAYA MALAYSIA.
    Conforms to Standard:
    Pole design : BS EN 40
    Material : BS EN 10025 S275 / JIS G3101 SS400
    Welding : BS 5135
    Galvanizing : BS 729 / ISO 1461 ASTM A 123

    Length of per section

    Within 14m once forming without slip joint.

    high mast pole suit for

    city square,wharf,stadium

    Option of high mast pole

    Height from 20m to 35m
    Flange mounted or planted type

    Production Process of high mast pole

    Raw material testCuttingMolding or bendingWelidng (longitudinal )Dimension verifyFlange weldingHole drillingCalibrationDeburrGalvanization or powder coating ,paintingRecalibrationThreadPackages
