    12m Galvanized 2.5mm square Light Poles Powder Coating with Cross Arms

    Ask Lasest Price
    Brand Name : MilkyWay
    Model Number : Galvanized Steel Pole
    Certification : ISO9001/BV/
    Price : Negotiation
    Payment Terms : T/T, L/C at sight
    Supply Ability : 300pcs per day
    Delivery Time : 20 working days after received your payment
    • Product Details
    • Company Profile

    12m Galvanized 2.5mm square Light Poles Powder Coating with Cross Arms

    12M Single Arm Street Light Poles Q235 Material for Park Lighting


    Specifications:

    Type

    Street Lamp pole, lamp post . Lamp column

    Shape

    Conoid ,Multi-pyramidal,Columniform,polygonal or conical

    Material

    Usually Q345B/A572,minimum yield strength>=345n/mm2
    Q235B/A36,minimum yield strength>=235n/mm2
    As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,

    SS400, SS490ST52

    Torlance of dimenstion

    -0.02

    Design Load in Kg

    300~ 1000 Kg appliced to 50cm from the to pole

    Surface treatment

    Hot dip galvanized Following ASTM A 123, color polyester power

    or any other standard by client required.

    Standard

    Octagonal tapered column
    Certified by SIRIM QAS INTERNATIONAL.
    Approved by JABATAN KERJA RAYA MALAYSIA.
    Conforms to Standard:
    Pole design : BS EN 40
    Material : BS EN 10025 S275 / JIS G3101 SS400
    Welding : BS 5135
    Galvanizing : BS 729 / ISO 1461 ASTM A 123

    Length of per section

    Within 14m once forming without slip joint.

    Suit for

    Highway
    Roadway
    Residential subdivisions
    Commercial development

    Option

    Height from 6m to 12m
    Flange mounted or planted type
    Variable arm length from 0.125m to 3.0m with single or double arm type
    Variable spigot size from 35mm to 60mm.

    Production Process

    Raw material test → Cutting →Molding or bending →

    Welidng (longitudinal )→Dimension verify →Flange welding

    →Hole drilling →Calibration →Deburr→Galvanization or powder coating ,painting

    →Recalibration →Thread→Packages



    The information to inquiry or purchase
    -Steel pole height
    -Dimension of the flange
    -Position and dimension of the service door
    -Cross arm type and length,the position to install in the steel pole
    -The method to fix the cross arm(use bolt to connect or use one or two template to weld in the steel pole to install the cross arm)
    -Wind speed
    -Destination port
    -Other.


    Package:

    Our poles as normal cover by Mat or straw bale at the top and bottom ,
    anyway also can following by client required , each 40HC or OT can
    loading how many pcs will calculation base on the client actually
    specification and data.
