Company Information
Established in 1991,Jiangsu Milky Way Steel Poles is located in
Wuxi,East of China ,near one of the largest sea port of China
,Shanghai,Port .
Our Products have been widely used in the power transmsion ,signal
transmission and ligting for street ,road ,square ,palaestra.and so
on.
We have plenty of export experience . Since our first overseas
order from Pakstan in 1991 of 132 KV transmission poels ,our
products have been deliveried to more than 70 contries and areas
,including America,Australia ,Russia ,Genmery ,Span,Philippines
,Malaysia , Dominica, Congo, Togo and Guniea so on.
Specification
| Material: | high quality Q345 hot rolled steel |
| Mounting Height: | 3-30m or according to the requirements of customers |
| Shape of pole: | Round,conical,octagonal,square,mid hinged,polygonal shafts are made
of steel sheet that folded into required shape and welded
longitudinally by automaticarc welding machine
|
| Brackets: | Single or double brackets are in the shape and dimension as per
customers requirement |
| Base plate: | Base plate is square or round in shape with slotted holes for
anchor bolt and dimension as per customers requirement
|
| Groung mounted: | The length buried underground as per customers requirement
|
Galvanizing:
| Hot dip galvanization with thickness of 80-100µm average
|
| Powder coating: | Pure polyester powder painting, color is optional |
Production Process
Our factory own advance production line, machine including bending
calibration machine, hydraulic plate shears machine, shears
machine, slitting machine, 208T hydraulic straightener, etc. All
the purpose is to produce good quality steel poles.
The fabrication process as cut plate, bending, forming, automatic
welding, drill holes, quality check before galvanized, hot dip
galvanized and powder coating, finally quality check according by
client’s required.
Features
1. We can supply the product base on client required drawing ,but
also can supply the design for any kinds of lamp poles ,electric
poles ,street lighting poles, high mast poles ,garden light poles ,
outdoor lighting ,outdoor lighting poles ,flag poles ,traffic light
poles ,lighting ,road lighting pole.
2. Matercial :hot rolled coil from Q235 to Q460 ,ASTM573 GR65, GR50
,SS400, SS490,ST52-3
3. Deal: Hot dip galvanized Following ASTM A 123 or any other
stardand by client required.
4. Packing: Plastic bulble , Mat &Straw Bale or following
client required
5. Length : within 16meters once forming( single section)
6. Thickness: from 1mm to 25mm
7. Shape: polygonal(6-side,8side,12-side,16side) round tapered.
8. 110KV to 220kv
9. Easy install and maintenance.
