160FT Steel Material Mono Pole Tower For Telecommunication With CAD
Shop Drawing
| product name | Electric Galvanized Steel Tower Telecommunication Mono Pole Tower
For
Communication |
type polygonal pipe steel pipe
for overheadline project | Straight Pole ,Tensile Pole ,Turn Pole |
| Suit for | Electricity distribution |
| Shape | Conoid ,Multi-pyramidal,Columniform,polygonal or conical |
| Material | Usually Q345B/A572,minimum yield strength>=345n/mm2
Q235B/A36,minimum yield strength>=235n/mm2
As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400,
SS490, to ST52 |
| power | 10 KV ~550 KV |
| Torlance of the dimenstion | +- 2% |
| Safety Factor | Safety factor for conducting wine : 8 Safety factor for grounding wine : 8 |
| Electroshock resistant protective grade | Grade Ⅰ |
| The casing anti-corrosion performance | Class Ⅱ |
| Working atmosphere of lighting fixture | -35 ℃~+45 ℃ |
| Surface treatment | Hot dip galvanized Following ASTM A 123, color polyester power or
any other standard
by client required. |
| Joint of Poles | Insert mode,innerflange mode,face to face joint mode . |
| Wind Speed | 160 Km/Hour |
| Minimum yield strength | 355 mpa |
| Minimum ultimate tensile strengt | 490 mpa |
| Max ultimate tensile strength | 620mpa |
| Standard | ISO 9001 |
| Length of per section | Within 14m once forming without slip joint |
| Welding | We has past flaw testing.Internal and external double welding makes
the welding beautiful in shape
Welding Standard :AWS (American Welding Society ) D 1.1 |
| Thickness | 1 mm to 30 mm |
| Production Process | Rew material test → Cuttingj →Molding or bending →Welidng (longitudinal )→Dimension verify
→Flange welding →Hole drilling →Calibration → Deburr→Galvanization or powder coating ,painting →Recalibration →Thread →Packages |
| Packages | Our poles as normal cover by Mat or straw bale at the top and
bottom ,anyway also can
following by client required , each 40HC or OT can loading how many
pcs will calculation base
on the client actually specification and data. |
| Style | Size and styles are veriable as per customer request |
Project:
We have completed many big and important project all over the world
and win the trust of our client.
Milky Way monopoles feature:
Minimum of 65 ksi high-strength steel
Slip-sleeve tapered sections
Steel templates to assure proper base bolt alignment
Step bolt working rings at handhole levels
Loop step bolts at all working points
Flanged Pipe Poles
Milky Way flanged pipe poles are capable of carrying a variety of
communication applications. Internally and externally flanged, they
are custom-engineered to heights that meet your specifications.
Our pipe poles feature:
Steel templates to assure proper base bolt alignment
Step bolt working rings at handhole levels
Loop step bolts at all working points
Milky Way offers a variety of pole types to meet your specific
communication requirements. Flanged Steel Poles and Tapered Steel
Poles feature designs that blend well into the environment and
require minimum space for installation.
Two Different Type:
Flanged Steel Poles
Flanged Steel Poles are easy to handle and install. Precision
fitted connections allow quick assembly of modular sections and the
top platform, sidearms or mounting frame. Pole sections are
available with identical base flange plates, allowing for
simplified modifications of mounting heights and antenna
reconfigurations when required.
Tapered Steel Poles
Tapered Steel Poles are designed with base diameters from 2 feet to
6 feet. These minimal site requirements lower lease costs. Tapered
poles can be installed quickly, while meeting the demands of GSM
PCS, GSM cellular, and other applications. All poles are hot dipped
galvanized for long lasting corrosion protection and with unmatched
attention to detail and design, these poles offer extremely
efficient strength to cost ratio.
Features Include:
infinitely rotatable mounting frame or platform
quick installations
variety of types, for different applications
eights in excess of 200 feet
microwave capable
minimal space requirements
full line of accessories, lights and mounts
Monopole Reinforcing Elements
Flat Plate Reinforcing
Anchor Rod Brackets
Base Stiffeners / Gussets
Welded and Bolted Flange / Bridge Stiffeners
Monopole Extensions
